Trailer PRONAR T655

Name: Trailer PRONAR T655
SKU: 6906
Availability: InStock

34 000,00 zł

To order

Pronar trailer T655– single axle designed for municipal purpose and the smallest produced at once. Offered in unique orange colourway. The Three-way tipping system of the loading case provides high level functionality. Beside this, high quality, reliable and durable axles distinguish them from their competition. The small dimensions and load capacity of two and half tons make them perfect for municipality. In order to its small dimensions it can be connected to any type of tractor.

Categories: Agricultural machinery, Trailers, Uniaxial

Ask about price

Ask for the price of the product (Trailer PRONAR T655)

Technical data
Basic equipment

Technical data
Technically permissible total weight:	3500	[kg]
Permissible total weight:	2980	[kg]
Load capacity:	2000	[kg]
Empty weight:	980	[kg]
Load volume:	2.1	[m ³]
Loading space:	4.1	[m ²]
Loading case inside length:	2910	[mm]
Loading case inside width:	1410	[mm]
Dimensions: length/width/height:	4420/1595/1390	[mm]
Sidewall height:	500	[mm]
Floor/wall thickness:	3/2	[mm]
Platform height, measured from the ground:	850	[mm]
Wheel track:	1150	[mm]
Suspension:	fixed
Hitch-ring load:	480	[kg]
Tyres:	10.0/75-15.3
Maximum speed:	30	[km/h]
Tipping system:	3-side
Number of tipping cylinder sections:	4
Tipping cylinder (piston stroke/oil requirement/working pressure)	1300mm/8L/160bar
Tractor power requirement:	20.8/15.3	[hp/kW]
Tipping angle (backwards/sides):	50/46	[˚]

Standard equipment
Loading case with universal system of sidewalls opening
Central locking system
Tipping frame: triangular made of open profiles
Drawbar: lower transportation hitch with Ø50 fixed towing eye
Drawbar support: supporting wheel
Braking system: single line air or double line air or hydraulic
Parking brake with crank
12V lighting system with rear electric socket
Tipping system with cut-off valve
Three side tipping system
Sidewalls made of PRONAR profiles 500 mm
Double-component chemically hardened painting materials
Wheel chocks and racks
Tipping frame painting colour: black RAL9005
Side walls painting colour: orange RAL2008
Mechanical support of the loading case
